Lightweight Polyester Lifting Slings Safety Protection Sleeve Attached
| Place of Origin: | CHINA |
| Brand Name: | Dahua Sling |
| Certification: | CE GS ISO |
| Model Number: | eye eye sling 1tonne |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 8 |
| Packaging Details: | Package: Shrink Wrap, carton and pallet |
| Delivery Time: | 20-30 days for one container |
| Supply Ability: | 5 containers per month |
Detailed Product Description
| Material: | High Tenacity Polyester Yarn | W.L.L: | 5000kg |
|---|---|---|---|
| Sling Color: | Red | Size: | 150mm Width, Length As Request |
| Logo Printing: | We Do It Oursleves | Eye Protector: | Available |
| Place Of Origin: | China (Mainland) | Brand Name: | Dauhua |
| Model Number: | Web Sling | ||
| High Light: | industrial lifting slings,crane lifting belt | ||
Polyester Flat Web Lifting Slings Polyester Webbing Slings 1 Ton to 10 Ton safety factor 6:1 with all packing detaills
| Eye-eye webbing sling |
| Material: A-A grade Polyester |
| Safety Factor: 6:1 7:1 8:1 |
| Certificate:CE |
| Length: As required Color: Color code |
| Standard: ISO4878 EN1492-1 ASME B30.9 |
| Characteristic: PU impregnated ,WLL & Length printed,Low elongation |
| Package:Single packed in shrinking foil or plastic with Certificate of Conformity |
| Eyes flat sling Product Specifications | ||||||||
| Safety factor(6:1) | ||||||||
| Product Specifications | Product ID | working load | Breaking strength | Ribbon width | packing | weight | color code | packing size |
| (ton*m) | (KG) | (MM) | quantity | (kg/con) | (CM) | |||
| 1*1 | 69604 | 1000 | 6000 | 25 | 15 | 29 | 268C | 27*27*12.8 |
| 1*2 | 69605 | 1000 | 6000 | 25 | 15 | 26 | 268C | 27*27*25.6 |
| 1*3 | 69606 | 1000 | 6000 | 25 | 10 | 28 | 268C | 53*14.5*19.2 |
| 1*4 | 69607 | 1000 | 6000 | 25 | 10 | 30 | 268C | 53*14.5*25.6 |
| 1*5 | 69608 | 1000 | 6000 | 25 | 50 | 27 | 268C | 53*14.5*32 |
| 1*6 | 69609 | 1000 | 6000 | 25 | 25 | 25 | 268C | 53*14.5*38.4 |
| 1*8 | 69610 | 1000 | 6000 | 25 | 25 | 26 | 268C | 53*14.5*30.72 |
| 2*1 | 69611 | 2000 | 12000 | 50 | 15 | 22 | 363C | 35*27*16 |
| 2*2 | 69612 | 2000 | 12000 | 50 | 15 | 26 | 363C | 53*27*22.4 |
| 2*3 | 69613 | 2000 | 12000 | 50 | 10 | 25 | 363C | 53*27*16.8 |
| 2*4 | 69614 | 2000 | 12000 | 50 | 6 | 25 | 363C | 53*27*22.4 |
| 2*5 | 69615 | 2000 | 12000 | 50 | 6 | 31 | 363C | 53*27*16.8 |
| 2*6 | 69616 | 2000 | 12000 | 50 | 15 | 24 | 363C | 53*27*20.16 |
| 2*8 | 69617 | 2000 | 12000 | 50 | 15 | 32 | 363C | 53*27*17.92 |
| 2*10 | 69618 | 2000 | 12000 | 50 | 10 | 26 | 363C | 53*27*22.4 |
| 3*1 | 69619 | 3000 | 18000 | 75 | 10 | 24 | 116C | 35*39.5*17.14 |
| 3*2 | 69620 | 3000 | 18000 | 75 | 6 | 17 | 116C | 53*39.5*12 |
| 3*3 | 69621 | 3000 | 18000 | 75 | 6 | 25 | 116C | 53*39.5*18 |
| 3*4 | 69622 | 3000 | 18000 | 75 | 4 | 25 | 116C | 53*39*14.4 |
| 3*5 | 69623 | 3000 | 18000 | 75 | 15 | 31 | 116C | 53*24.5*18 |
| 3*6 | 69624 | 3000 | 18000 | 75 | 10 | 24 | 116C | 53*24.5*14.4 |
| 3*8 | 69625 | 3000 | 18000 | 75 | 10 | 32 | 116C | 53*24.5*19.2 |
| 3*10 | 69626 | 3000 | 18000 | 75 | 6 | 30 | 116C | 53*24.5*24 |
| 4*2 | 69846 | 4000 | 24000 | 100 | 15 | 22 | 8C | 53*32*11.2 |
| 4*3 | 69847 | 4000 | 24000 | 100 | 15 | 25 | 8C | 53*32*16.8 |
| 4*4 | 69848 | 4000 | 24000 | 100 | 10 | 25 | 8C | 53*32*22.4 |
| 4*5 | 69849 | 4000 | 24000 | 100 | 10 | 31 | 8C | 53*32*28 |
| 4*6 | 69850 | 4000 | 24000 | 100 | 6 | 32 | 8C | 53*32*13.44 |
| 4*8 | 69851 | 4000 | 24000 | 100 | 6 | 32 | 8C | 53*32*17.92 |
| 4*10 | 69852 | 4000 | 24000 | 100 | 4 | 26 | 8C | 53*22*22.4 |
| 5*2 | 69627 | 5000 | 30000 | 125 | 15 | 22 | 1787C | 53*39.5*12.8 |
| 5*3 | 69628 | 5000 | 30000 | 125 | 10 | 26 | 1787C | 53*27*19.2 |
| 5*4 | 69629 | 5000 | 30000 | 125 | 10 | 28 | 1787C | 53*27*25.6 |
| 5*5 | 69630 | 5000 | 30000 | 125 | 6 | 34 | 1787C | 53*27*19.2 |
| 5*6 | 69631 | 5000 | 30000 | 125 | 6 | 30 | 1787C | 53*27*23.04 |
| 5*8 | 69632 | 5000 | 30000 | 125 | 4 | 27 | 1787C | 53*27*20.48 |
| 5*10 | 69633 | 5000 | 30000 | 125 | 4 | 33 | 1787C | 53*27*25.6 |
| 8*2 | 69634 | 8000 | 48000 | 200 | 4 | 30 | 3005C | 53*21.5*9.6 |
| 8*3 | 69635 | 8000 | 48000 | 200 |
| |||
