Single / Double Ply Rock Lifting Sling , Purple Webbing Lifting Slings Safety
| Place of Origin: | CHINA |
| Brand Name: | Dahua Sling |
| Certification: | CE GS ISO |
| Model Number: | eye eye sling 1tonne |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 1 |
| Packaging Details: | carton and pallet |
| Delivery Time: | 20-30 days for one container |
| Supply Ability: | 5 containers per month |
| Material: | High Tenacity Polyester Yarn | W.L.L: | 1000KG - 20,000kg |
|---|---|---|---|
| Length: | 1 Meter - 25 Meters | Safety Factor: | 7:1 |
| Standard: | EN 1492 | Elongation: | Less Than 7% |
| Shape: | EYE EYE | Sling Color: | Purple |
| High Light: | industrial lifting slings,crane lifting belt | ||
Dahua Sling EN 1492 standard flat eye eye lifting sling 1000kg WLL 1 meter
What Specification of Flat webbing sling?
| Product Name | Polyester webbing sling |
| Material | high tenacity polyester |
| Width | 25mm-300mm |
| Length | From 1m to 20m up, can be customized as required |
| W.L.L. | From 1Ton to 12 Ton or up |
| Safety Factor | 4:1,5:1,6:1,7:1 all available |
| Layer | Single ply, double ply, three ply and four ply |
| Color | According to EN standard or as required |
| Standard | According to Machinery Directive 2006/42/EC and EN1492-1:2008+A1 |
| Elongation | <=7% |
| Temperature | ﹣40℃~100℃ |
| Lifting Eye types | 1.Flat Eye 2.Reversed Eye 3.Folded Eye 1/2 Width from 1 Side 4.Folded Eye 1/2 width from 2 sides 5.Folded Eye 1/3 width Notes: all above 5 lifting eye types are available. |
| Package | Cartons and pallets/As required |
Detailed Product Description:
Webbing sling, it divides into single layer loop type and many layer loop type ,sewed up with different method
Size can adjust according to customers' requirements
The broad loading area can reduce the bearing of surface
Protect whose surface are smooth and refined from destroying
| Polyester | WLL 1T | WLL 2T | WLL 3T | WLL 4T | WLL 5T | WLL 6T | WLL 8T | WLL 10T | WLL 12T |
| Straight life up to 45 | 1.400 | 2.800 | 4.200 | 5.600 | 7.000 | 8.400 | 11.200 | 14.000 | 16.800 |
| Chocked life up to 45 | 1.120 | 2.240 | 3.360 | 4.480 | 5.600 | 6.720 | 8.960 | 11.200 | 13.440 |
| Straight life 40-60 | 1.000 | 2.000 | 3.000 | 4.000 | 5.000 | 6.000 | 8.000 | 10.000 | 12.000 |
| Chocked life 45-60 | 800 | 1.600 | 2.400 | 3.200 | 4.000 | 4.800 | 6.400 | 8.000 | 9.600 |
| Color | Purple | Green | Yellow | Grey | Red | Brown | Blue | Orange | Orange |
Nanjing Dahua Speical belt Knit co.,ltd, is located in Nanjing, China, is a professional company which owns one stop service from research, design, production ,sale to service.
We started our business earlier at t1993. We are a qualified supplier and we have obtained ISO9001:2000 and CE Quality System Certificate for Swivel Hoist Ring. Our main products include lifting and lashing serious, more than 300 kinds of specifications. Location, harmonious human environment and outstanding industrial advantages have made our company become the ideal place for foreign investment. Up till now, our products are sold to South Korea, the United Kingdom, the United States, Germany, Russia, Vietnam, Philippine, Taiwan and other countries and regions. With our effort, a good reputation has been erecting among the majority of users at home and abroad.
OUrs Advantages:
Certifications: ISO 9001,CE,CSS&Patents.
Factory History: A decade more manufactures experience.
Factory Location: Nanjing, China
Management Certification: ISO 9001,CE,GS.
